YH-121319 Small Powder Coating Booth for Wheels from Inovatec Machinery
- Technical Data
- Video
Specifications | |
Model | YH-121319P |
Overall Size | W1200 x D1300 x H1900 mm |
Working Size | W1100 x D800 x H1700 mm |
Power supply | Electric |
Nominal power | 1.5 kw |
Voltage | 110V/220V/380V can be customized as local |
Frequency | 50-60hz |
Filters | Polyester |
Filters count | 2 |
Filters hang type | Easy for change |
Filters cleaning system | Pneumatic |
Warranty | 12 months |
Optional size | |
Overall Size(WxDxH mm) | Overall Size (WxDxH mm) |
1000 x 1300 x1800 | 2000 x 1500 x2000 |
1200 x 1500 x1800 | 2500 x 1800 x2000 |
1500 x 1500 x1800 | 3000 x 1800 x2000 |
We could customize any size and specifications for you. | |
Related Products
YH-121319P Small Powder Coating Booth for Wheels — powder recovery and filtration for wheel refinishing
The YH-121319P is a compact powder coating booth designed specifically for wheel powder coating workstations. While a powder coating gun applies the powder, overspray that misses the wheel is captured and filtered inside the booth rather than escaping into the shop — recovering usable powder, keeping the workspace clean and protecting operators from dust exposure.
Two polyester filters with pneumatic self-cleaning keep filtration efficient without stopping the line to manually clean. The 1100 × 800 × 1700 mm working space fits most wheel sizes, and the booth can be customized to larger dimensions to suit your line.
- Captures and recovers overspray powder — reduces waste and material cost
- Two polyester filters with pneumatic self-cleaning for continuous operation
- Easy-change filter design for fast maintenance
- Customizable sizes available for larger workstations
At a glance
| Working size | W1100 × D800 × H1700 mm |
| Overall size | W1200 × D1300 × H1900 mm |
| Nominal power | 1.5 kW |
| Filters | Polyester × 2 |
| Filter cleaning | Pneumatic (automatic) |
| Warranty | 12 months |
How the powder coating booth works
The booth sits around the wheel while the operator applies powder with a coating gun. Overspray is drawn through the filters, captured and settled for recovery. The pneumatic filter cleaning pulse keeps the filters clear without stopping the line.
| Step | What happens |
|---|---|
| 1. Apply | Operator sprays powder onto the wheel inside the booth |
| 2. Capture | Overspray is drawn into the filtration unit and captured by polyester filters |
| 3. Clean | Pneumatic pulse automatically cleans the filters, keeping airflow consistent |
| 4. Recover | Settled powder is collected and can be reused, reducing waste |
Who the YH-121319P is built for
Wheel refinishing shops adding powder coating — a compact booth keeps the spray station clean and recovers powder without a large footprint or complex installation.
Shops concerned about material cost — powder recovery from overspray reduces waste and lowers the cost per wheel, especially on high-volume days.
Operators working in enclosed spaces — proper filtration keeps airborne powder out of the shop environment and away from operators.
Optional sizes
The YH-121319P can be customized to larger dimensions. Standard optional sizes available:
| Overall size (W×D×H mm) | Overall size (W×D×H mm) |
|---|---|
| 1000 × 1300 × 1800 | 2000 × 1500 × 2000 |
| 1200 × 1500 × 1800 | 2500 × 1800 × 2000 |
| 1500 × 1500 × 1800 | 3000 × 1800 × 2000 |
Custom sizes and specifications available on request.
YH-121319P full specifications
| Model | YH-121319P |
| Overall size | W1200 × D1300 × H1900 mm |
| Working size | W1100 × D800 × H1700 mm |
| Power supply | Electric |
| Nominal power | 1.5 kW |
| Voltage | 110V / 220V / 380V (customizable) |
| Frequency | 50–60 Hz |
| Filters | Polyester |
| Filter count | 2 |
| Filter hang type | Easy for change |
| Filter cleaning system | Pneumatic |
| Warranty | 12 months |
Specifications subject to change without notice. Custom sizes and voltage available on request.
Why Inovatec — a finishing partner, not just a machine seller
| 15+ Years in finishing equipment A full range of wheel refinishing machines and media. | 24h Reply on inquiries Technical questions answered fast so your buying decision isn’t stuck waiting. | Custom Size & spec available We can customize any size and specification for your line. |
| 60+ Countries served Export packing and documentation handled as standard. | CE Compliant build Machines built to meet export safety requirements. | Full Wheel line supplier Ovens, guns, booths, polishers — source your whole line from one maker. |
Download the specification sheet
Full specs and optional sizes in a one-page datasheet you can share with your team.
↓ Download YH-121319P Spec Sheet (PDF)
